2JQ 500
RoHS
/
Package 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 500MA 350VAC 140VDC
PDF
/
Inventory: 6572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Holder
Package / Case 2AG, 5mm x 15mm
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 2JQ
Size / Dimension 0.201Diax0.543L 5.10mmx13.80mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature RATED BREAKING CAPACITY: 150 A
Voltage - Rated DC 140V
Current Rating (Amps) 500mA
Reference Standard CE; CSA; PSE; UL
Voltage - Rated AC 350V
Approval Agency CE, CSA, cURus
Body Length or Diameter 5.1mm
Physical Dimension 5.1mm x 13.8mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 100A AC 150A DC
Rated Current 0.5A
Melting I2t 0.1
DC Cold Resistance 0.59Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Fuse Size 5x15mm
Dimensions
Body Height 13.8mm
Compliance
RoHS Status Non-RoHS Compliant
