0659P2500-13
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 2.5A 250VAC 5X20MM
PDF
/
Inventory: 992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 19.9898mm
Technical
DC Cold Resistance 0.036Ohms
Melting I2t 25
Breaking Capacity @ Rated Voltage 1.5kA
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Approval Agency CQC, cURus, PSE, VDE
Voltage - Rated AC 250V
Current Rating 2.5A
Current Rating (Amps) 2.5A
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 36mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 0659P
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case 5mm x 20mm (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
