RSF43Y100RF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Float, Level Sensors
Description
FLOATSWITCH HORZ .6A NYLON
PDF
/
Buying Options
Total Price: USD $19.95
Unit Price: USD $19.9496
≥1 USD $19.9496
≥10 USD $19.00712
≥100 USD $18.142784
≥500 USD $17.604048
Inventory: 66
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Minimum Liquid Specific Gravity 0.85
Switch Actuation Level 0.787 (20mm)
Switching Current 600mA
Throw Configuration SPST
Output Current 600mA
Cable Length 1m
Output Configuration SPST-NC/NO
Current 600mA
Output Type Switch (Single Float)
Voltage - Rated AC 240V
Voltage - Rated DC 120V
Voltage - Rated 120VDC 240VAC
Min Operating Temperature -20°C
Max Operating Temperature 75°C
Type Liquid
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RSF40
Published 2008
Operating Temperature -20°C~75°C
Physical
Material - Housing & Prism Nylon
Body Material Nylon
Housing Material Nylon
Material Nylon
Number of Pins 2
Mounting Type Panel Mount, M16x2 Thread
Mount Horizontal, Panel
Supply Chain
Factory Lead Time 4 Weeks
