RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD2A Nonstandard 0.228Lx0.205W 5.80mmx5.20mm 10muH
PDF
/
Buying Options
Total Price: USD $14.13
Unit Price: USD $14.1265
≥1 USD $14.1265
≥10 USD $11.59095
≥100 USD $11.229
≥500 USD $10.8661
≥1000 USD $10.50415
Inventory: 1093
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant

Dimensions

Width 5.207mm
Length 5.7912mm
Height Seated (Max) 0.191 4.85mm

Technical

Current - Saturation 2.5A
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 26MHz
DC Resistance (DCR) 100mOhm Max
Test Frequency 10kHz
Inductance 10μH
Current Rating 2.2A
Shielding Unshielded
Current Rating (Amps) 2.2A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.228Lx0.205W 5.80mmx5.20mm
Series WE-PD2A
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Supplier Device Package 5848
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
