784771022
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDA Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 2.2muH
PDF
/
Inventory: 5847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 11.9888mm
Length 11.9888mm
Height Seated (Max) 0.248 6.30mm
Technical
Current - Saturation 10.5A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 82.7MHz
DC Resistance (DCR) 12.5mOhm Max
Test Frequency 100kHz
Inductance 2.2μH
Current Rating 7.2A
Shielding Shielded
Current Rating (Amps) 7.2A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Series WE-PDA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Nickel Zinc Ferrite (NiZn)
Supplier Device Package 1260
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
