74479887124C
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PMI 1008 (2520Metric) 0.098Lx0.079W 2.50mmx2.00mm 240nH
PDF
/
Inventory: 7102
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 2.0066mm
Length 2.4892mm
Height Seated (Max) 0.039 1.00mm
Technical
RMS Current (Irms) 3.8A
Inductance Tolerance 20%
Current - Saturation 5A
Inductance Frequency - Test 1MHz
Q @ Freq 15 @ 1MHz
Frequency - Self Resonant 120MHz
DC Resistance (DCR) 24mOhm
Test Frequency 1MHz
Inductance 240nH
Case Code (Imperial) 1008
Case Code (Metric) 2520
Current Rating 3.8A
Shielding Shielded
Current Rating (Amps) 3.8A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Multilayer
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series WE-PMI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 1008 (2520 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
