7447789004
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 4.7muH
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.2088
≥1 USD $2.2088
≥10 USD $1.9712
≥100 USD $1.8304
≥500 USD $1.76
≥1000 USD $1.6896
Inventory: 1158
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 4.535924g
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PD Robust
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 35mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.9A
Shielding Shielded
Depth 7.6mm
Current Rating 2.9A
Military Standard Not
Inductance 4.7μH
Test Frequency 1kHz
DC Resistance (DCR) 35mOhm Max
Max DC Current 2.9A
Frequency - Self Resonant 61MHz
Inductance Frequency - Test 1kHz
Current - Saturation 3.9A
Inductance Tolerance 20%
DC Current 2.9A
RMS Current (Irms) 2.9A
Series Resistance 35mOhm
Dimensions
Height 3.2mm
Height Seated (Max) 0.138 3.50mm
Length 7.3mm
Width 7.3mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
