7447789002
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 2.2muH
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 1134
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 23mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 4.02A
Shielding Shielded
Current Rating 4.02A
Lead Pitch 4mm
Inductance 2.2μH
Test Frequency 1kHz
DC Resistance (DCR) 23mOhm Max
Max DC Current 4.02A
Frequency - Self Resonant 115MHz
Inductance Frequency - Test 1kHz
Current - Saturation 4.8A
Inductance Tolerance 20%
RMS Current (Irms) 4.02A
Series Resistance 23mOhm
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD Robust
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height 3.2mm
Height Seated (Max) 0.138 3.50mm
Length 7.3mm
Width 7.3mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
Physical
Material - Core Ferrite
Weight 4.535924g
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
