7447783220

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Tape & Reel (TR) Fixed Inductor -40C~150C 18MHz 115mOhm Max 22muH
PDF
/
Buying Options
Total Price: USD $1.95
Unit Price: USD $1.947741
≥1 USD $1.947741
≥10 USD $1.837487
≥100 USD $1.733479
≥500 USD $1.635356
≥1000 USD $1.542793
Inventory: 1180
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.138 3.50mm

Technical

Current - Saturation 2.15A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 18MHz
DC Resistance (DCR) 115mOhm Max
Inductance 22μH
Shielding Shielded
Current Rating (Amps) 1.75A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.291Lx0.287W 7.40mmx7.30mm
Series WE-PD Performance
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
