744778133
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Tape & Reel (TR) fixed air core inductor -40C~125C 16MHz 240mOhm Max 33muH
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5776
≥1 USD $0.5776
≥10 USD $0.47405
≥100 USD $0.45885
≥500 USD $0.4446
≥1000 USD $0.4294
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Length 7.3mm
Height Seated (Max) 0.134 3.40mm
Height 3.2mm
Technical
Inductance Tolerance 20%
Current - Saturation 1.15A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 16MHz
Max DC Current 1.22A
DC Resistance (DCR) 240mOhm Max
Inductance 33μH
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 1.22A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
