744778002
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Tape & Reel (TR) Fixed Inductor -40C~125C 67MHz 20mOhm Max 2.2muH
PDF
/
Buying Options
Total Price: USD $17.97
Unit Price: USD $17.97305
≥1 USD $17.97305
≥10 USD $14.74685
≥100 USD $14.2861
≥500 USD $13.82535
≥1000 USD $13.3646
Inventory: 1168
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Length 7.3mm
Height Seated (Max) 0.134 3.40mm
Height 3.2mm
Technical
Inductance Tolerance 20%
Current - Saturation 4.8A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 67MHz
Max DC Current 4.8A
DC Resistance (DCR) 20mOhm Max
Inductance 2.2μH
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 4.02A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
