744777928
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 820muH
PDF
/
Buying Options
Total Price: USD $19.1
Unit Price: USD $19.1045
≥1 USD $19.1045
≥10 USD $15.67595
≥100 USD $15.18575
≥500 USD $14.69555
≥1000 USD $14.2063
Inventory: 1751
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 7345
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PD Robust
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 5.2Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 210mA
Shielding Shielded
Depth 7.3mm
Current Rating 210mA
Inductance 820μH
Test Frequency 1kHz
DC Resistance (DCR) 5.2Ohm Max
Max DC Current 210mA
Frequency - Self Resonant 2.8MHz
Inductance Frequency - Test 1kHz
Current - Saturation 260mA
Inductance Tolerance 20%
RMS Current (Irms) 210mA
Series Resistance 5.2Ohm
Dimensions
Height 1.5mm
Height Seated (Max) 0.177 4.50mm
Length 7.3mm
Width 7.2898mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
