RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Tape & Reel (TR) fixed air core inductor -40C~125C 4MHz 1.86Ohm Max 330muH
PDF
/
Buying Options
Total Price: USD $18.42
Unit Price: USD $18.42335
≥1 USD $18.42335
≥10 USD $15.1164
≥100 USD $14.64425
≥500 USD $14.1721
≥1000 USD $13.69995
Inventory: 1593
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant

Dimensions

Length 7.3mm
Height Seated (Max) 0.177 4.50mm
Height 4.5mm

Technical

Inductance Tolerance 20%
Current - Saturation 450mA
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 4MHz
Max DC Current 390mA
DC Resistance (DCR) 1.86Ohm Max
Inductance 330μH
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 390mA
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Supplier Device Package 7345
Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
