744765143A

Würth Elektronik
RoHS
RoHS RoHS compliant
Package 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-KI 0402 (1005Metric) 0.039Lx0.022W 1.00mmx0.55mm 43nH
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.362209
≥1 USD $0.362209
≥10 USD $0.341711
≥100 USD $0.322363
≥500 USD $0.304116
≥1000 USD $0.286908
Inventory: 1155
Minimum: 1
-
+

Technical Details

Physical

Number of Pins 2
Supplier Device Package 0402 (1005 Metric)
Material Ceramic
Weight 652.039032μg
Material - Core Ceramic
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-KI
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 810mOhm
Series Resistance 810mOhm
Inductance Tolerance 5%
Q Factor 25
Inductance Frequency - Test 250MHz
Q @ Freq 25 @ 250MHz
Frequency - Self Resonant 2.03GHz
Max DC Current 100mA
DC Resistance (DCR) 810mOhm Max
Test Frequency 250MHz
Inductance 43nH
Case Code (Imperial) 0402
Case Code (Metric) 1005
Frequency 250MHz
Current Rating 100mA
Depth 550μm
Shielding Unshielded
Current Rating (Amps) 100mA
Composition Ceramic, Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C

Supply Chain

Factory Lead Time 34 Weeks

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 550μm
Length 1mm
Height Seated (Max) 0.024 0.60mm
Height 500μm
