744765062A
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-KI 0402 (1005Metric) 0.039Lx0.022W 1.00mmx0.55mm 6.2nH
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.36608
≥100 USD $0.34056
≥500 USD $0.31504
≥1000 USD $0.2904
≥3000 USD $0.26488
Inventory: 2957
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 550μm
Length 1mm
Height Seated (Max) 0.024 0.60mm
Height 500μm
Technical
Series Resistance 83mOhm
Inductance Tolerance 5%
Q Factor 23
Inductance Frequency - Test 250MHz
Q @ Freq 23 @ 250MHz
Frequency - Self Resonant 5.8GHz
Max DC Current 760mA
DC Resistance (DCR) 83mOhm Max
Test Frequency 250MHz
Inductance 6.2nH
Case Code (Imperial) 0402
Case Code (Metric) 1005
Frequency 250MHz
Current Rating 760mA
Depth 550μm
Shielding Unshielded
Current Rating (Amps) 760mA
Composition Ceramic, Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 83mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
Series WE-KI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ceramic
Weight 652.039032μg
Material Ceramic
Supplier Device Package 0402 (1005 Metric)
Number of Pins 2
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 34 Weeks
