744764903
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-GFH Nonstandard 0.134Lx0.098W 3.40mmx2.50mm 3.3muH
PDF
/
Inventory: 2037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 2.4892mm
Length 3.4036mm
Height Seated (Max) 0.094 2.40mm
Technical
Inductance Tolerance 20%
Inductance Frequency - Test 1.25MHz
Q @ Freq 25 @ 1.25MHz
Frequency - Self Resonant 79MHz
Max DC Current 1.05A
DC Resistance (DCR) 325mOhm Max
Test Frequency 1.25MHz
Inductance 3.3μH
Current Rating 1.05A
Shielding Unshielded
Current Rating (Amps) 1.05A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.134Lx0.098W 3.40mmx2.50mm
Series WE-GFH
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
