7447629068
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-GFH Nonstandard 0.098Lx0.079W 2.50mmx2.00mm 6.8muH
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.324577
≥1 USD $0.324577
≥10 USD $0.306202
≥100 USD $0.288876
≥500 USD $0.272525
≥1000 USD $0.257093
Inventory: 1129
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 2520
Material - Core Iron Powder
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series WE-GFH
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Current Rating (Amps) 450mA
Shielding Unshielded
Current Rating 450mA
Inductance 6.8μH
Test Frequency 7.96MHz
DC Resistance (DCR) 1.1Ohm Max
Max DC Current 450mA
Frequency - Self Resonant 61MHz
Q @ Freq 20 @ 7.96MHz
Inductance Frequency - Test 7.96MHz
Inductance Tolerance 20%
Dimensions
Height Seated (Max) 0.079 2.00mm
Length 2.4892mm
Width 2.0066mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
