7447629022
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-GFH Nonstandard 0.098Lx0.079W 2.50mmx2.00mm 2.2muH
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.312617
≥1 USD $0.312617
≥10 USD $0.294922
≥100 USD $0.27823
≥500 USD $0.262484
≥1000 USD $0.247618
Inventory: 1118
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 2.0066mm
Length 2.4892mm
Height Seated (Max) 0.079 2.00mm
Technical
Inductance Tolerance 20%
Inductance Frequency - Test 7.96MHz
Q @ Freq 20 @ 7.96MHz
Frequency - Self Resonant 115MHz
Max DC Current 650mA
DC Resistance (DCR) 600mOhm Max
Test Frequency 7.96MHz
Inductance 2.2μH
Current Rating 650mA
Shielding Unshielded
Current Rating (Amps) 650mA
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series WE-GFH
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Material - Core Iron Powder
Supplier Device Package 2520
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
