744760322A
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-RFI Nonstandard 0.090Lx0.067W 2.29mmx1.70mm 2.2muH
PDF
/
Buying Options
Total Price: USD $3.78
Unit Price: USD $3.781
≥1 USD $3.781
≥10 USD $3.1027
≥100 USD $3.0058
≥500 USD $2.9089
≥1000 USD $2.812
Inventory: 3747
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 1.7018mm
Length 2.286mm
Height Seated (Max) 0.058 1.48mm
Height 1.2mm
Technical
Inductance Tolerance 5%
Q Factor 15
Inductance Frequency - Test 7.96MHz
Q @ Freq 15 @ 7.96MHz
Frequency - Self Resonant 110MHz
Max DC Current 110mA
DC Resistance (DCR) 3.1Ohm Max
Test Frequency 7.96MHz
Inductance 2.2μH
Current Rating 110mA
Shielding Unshielded
Current Rating (Amps) 110mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.090Lx0.067W 2.29mmx1.70mm
Series WE-RFI
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Material - Core Ferrite
Weight 32.006612mg
Supplier Device Package 0805
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
