PB2020.222NL image
Favorite
PB2020.222NL image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description PB2020NL Nonstandard 0.940Lx0.820W 23.87mmx20.83mm 2.2muH
PDF
/
Buying Options
Total Price: USD $3.05
Unit Price: USD $3.0536
≥1 USD $3.0536
≥10 USD $2.5542
≥100 USD $1.99892
≥500 USD $1.832424
≥1000 USD $1.776887
≥3000 USD $1.721368
Inventory: 991
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite

Technical

Operating Temperature -40°C~130°C
Packaging Tube
Series PB2020NL
Size / Dimension 0.940Lx0.820W 23.87mmx20.83mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method Tray
Shielding NO
Number of Functions 1
Depth 20.83mm
Current Rating 21.8A
Inductance 2.2μH
DC Resistance (DCR) 2.8mOhm Max
Max DC Current 21.8A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 40A
Case/Size Code 9482

Dimensions

Height 10.16mm
Height Seated (Max) 0.400 10.16mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
