744760282A

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-RFI Nonstandard 0.090Lx0.067W 2.29mmx1.70mm 820nH
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.369735
≥1 USD $0.369735
≥10 USD $0.348813
≥100 USD $0.329063
≥500 USD $0.310434
≥1000 USD $0.29286
Inventory: 1445
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 1.25mm
Length 2.286mm
Height Seated (Max) 0.058 1.48mm
Height 1.2mm

Technical

Inductance Tolerance 5%
Q Factor 35
Inductance Frequency - Test 25.2MHz
Q @ Freq 35 @ 50MHz
Frequency - Self Resonant 215MHz
Max DC Current 300mA
DC Resistance (DCR) 1.5Ohm Max
Test Frequency 25.2MHz
Inductance 820nH
Case Code (Imperial) 0805
Case Code (Metric) 2012
Current Rating 300mA
Shielding Unshielded
Current Rating (Amps) 300mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.090Lx0.067W 2.29mmx1.70mm
Series WE-RFI
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C

Physical

Material - Core Ferrite
Weight 32.006612mg
Supplier Device Package 0805
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 56 Weeks
