744760215C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-KI Nonstandard 0.090Lx0.067W 2.29mmx1.70mm 150nH
PDF
/
Buying Options
Total Price: USD $3.24
Unit Price: USD $3.2376
≥1 USD $3.2376
≥10 USD $2.6562
≥100 USD $2.57355
≥500 USD $2.48995
≥1000 USD $2.4073
Inventory: 1139
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 1.7018mm
Length 2.286mm
Height Seated (Max) 0.058 1.48mm
Height 1.27mm
Technical
Series Resistance 560mOhm
Inductance Tolerance 5%
Q Factor 40
Inductance Frequency - Test 100MHz
Q @ Freq 40 @ 250MHz
Frequency - Self Resonant 920MHz
Max DC Current 400mA
DC Resistance (DCR) 560mOhm Max
Test Frequency 100MHz
Inductance 150nH
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 250MHz
Current Rating 400mA
Depth 1.7mm
Shielding Unshielded
Current Rating (Amps) 400mA
Composition Ceramic, Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 510mOhm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.090Lx0.067W 2.29mmx1.70mm
Series WE-KI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ceramic
Weight 40mg
Material Ceramic
Supplier Device Package 0805
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
