744760136A

Würth Elektronik
RoHS
RoHS RoHS compliant
Package 0805 (2012 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-KI 0805 (2012Metric) 0.079Lx0.049W 2.00mmx1.25mm 36nH
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.23232
≥100 USD $0.21384
≥500 USD $0.19536
≥1000 USD $0.18128
Inventory: 1028
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 2
Supplier Device Package 0805
Material Ceramic
Weight 40mg
Material - Core Ceramic

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-KI
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 60mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 500mA
Shielding Unshielded
Depth 1.25mm
Current Rating 600mA
Frequency 500MHz
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 36nH
Test Frequency 500MHz
DC Resistance (DCR) 180mOhm Max
Max DC Current 500mA
Frequency - Self Resonant 2GHz
Q @ Freq 60 @ 500MHz
Inductance Frequency - Test 250MHz
Q Factor 60
Inductance Tolerance 5%
Series Resistance 180mOhm

Dimensions

Height 1.2mm
Height Seated (Max) 0.055 1.40mm
Length 2mm
Width 1.25mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
