L-15W36NGV4E
RoHS
/
Package 0805 (2012 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 36NH 500MA SMD
PDF
/
Inventory: 2461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Supplier Device Package 0805 (2012 Metric)
Material - Core Ceramic
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2013
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±2%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 500mA
Shielding Unshielded
Current Rating 500mA
Inductance 36nH
Test Frequency 100MHz
Q @ Freq 60 @ 500MHz
Inductance Frequency - Test 100MHz
Dimensions
Height Seated (Max) 0.055 1.40mm
Length 2.0066mm
Width 1.2446mm
Compliance
RoHS Status RoHS Compliant
