744758315A
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Cut Tape (CT) Wirewound Inductor -40C~85C 250MHz 750mOhm Max 1.5muH
PDF
/
Inventory: 2191
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Supplier Device Package 1008 (2520 Metric)
Weight 32.006612mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
Series WE-RFH
Size / Dimension 0.102Lx0.083W 2.60mmx2.10mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Current Rating (Amps) 630mA
Shielding Unshielded
Current Rating 630mA
Case Code (Metric) 2520
Case Code (Imperial) 1008
Inductance 1.5μH
Test Frequency 7.96MHz
DC Resistance (DCR) 750mOhm Max
Max DC Current 630mA
Frequency - Self Resonant 250MHz
Q @ Freq 20 @ 7.96MHz
Inductance Frequency - Test 7.96MHz
Q Factor 20
Inductance Tolerance 5%
Dimensions
Height 990.6μm
Height Seated (Max) 0.075 1.90mm
Length 2.4892mm
Width 2.0066mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
