7447471022
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TIS Radial Vertical Cylinder 0.433Dia 11.00mm 2.2muH
PDF
/
Buying Options
Total Price: USD $2
Unit Price: USD $1.99934
≥1 USD $1.99934
≥10 USD $1.886172
≥100 USD $1.77941
≥500 USD $1.678688
≥1000 USD $1.58367
Inventory: 1211
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-TIS
Size / Dimension 0.433Dia 11.00mm
Tolerance ±20%
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 8.2A
Shielding Shielded
Current Rating 8.2A
Frequency 75MHz
Lead Pitch 5mm
Lead Diameter 650 μm
Inductance 2.2μH
Test Frequency 1kHz
DC Resistance (DCR) 8.8mOhm Max
Max DC Current 8.2A
Frequency - Self Resonant 75MHz
Inductance Frequency - Test 1kHz
Current - Saturation 10A
Inductance Tolerance 20%
RMS Current (Irms) 8.2A
Series Resistance 7.5mOhm
Dimensions
Diameter 11mm
Height 11.5mm
Height Seated (Max) 0.453 11.50mm
Length 11.5mm
Width 11mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
