744741222
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 2.2MH 210MA 11 OHM TH
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.113015
≥1 USD $1.113015
≥10 USD $1.050004
≥100 USD $0.990578
≥500 USD $0.934509
≥1000 USD $0.881617
Inventory: 1201
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.236 6.00mm
Technical
Current - Saturation 200mA
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 1.6MHz
DC Resistance (DCR) 11Ohm Max
Inductance 2.2mH
Shielding Unshielded
Current Rating (Amps) 210mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.335Dia 8.50mm
Series WE-TI
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Supply Chain
Factory Lead Time 12 Weeks
