744732015
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TI Radial Vertical Cylinder 0.307Dia 7.80mm 1.5muH
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.087039
≥1 USD $1.087039
≥10 USD $1.025509
≥100 USD $0.967466
≥500 USD $0.912698
≥1000 USD $0.86104
Inventory: 1169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 3mm
Height Seated (Max) 0.295 7.50mm
Height 8mm
Technical
RMS Current (Irms) 7A
Inductance Tolerance 20%
Current - Saturation 9A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 122MHz
Max DC Current 7A
DC Resistance (DCR) 10mOhm Max
Test Frequency 1kHz
Inductance 1.5μH
Lead Pitch 5mm
Current Rating 7A
Shielding Unshielded
Current Rating (Amps) 7A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 10mOhm
Type Wirewound
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.307Dia 7.80mm
Series WE-TI
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
