7447221472
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder, 4 Leads
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TIF Radial Vertical Cylinder 4Leads 0.433Dia 11.00mm 4.7mH
PDF
/
Buying Options
Total Price: USD $1.68
Unit Price: USD $1.6808
≥1 USD $1.6808
≥10 USD $1.44496
≥100 USD $1.24872
≥500 USD $1.09384
≥1000 USD $0.980329
Inventory: 197
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height Seated (Max) 0.669 17.00mm
Technical
RMS Current (Irms) 340mA
Inductance Tolerance 5%
Current - Saturation 420mA
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 410kHz
DC Resistance (DCR) 4.6Ohm Max
Test Frequency 10kHz
Inductance 4.7mH
Current Rating 340mA
Shielding Unshielded
Current Rating (Amps) 340mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.433Dia 11.00mm
Series WE-TIF
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Radial, Vertical Cylinder, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
