7447221471
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder, 4 Leads
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TIF Radial Vertical Cylinder 4Leads 0.433Dia 11.00mm 470muH
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.446999
≥1 USD $1.446999
≥10 USD $1.365092
≥100 USD $1.287821
≥500 USD $1.214928
≥1000 USD $1.146156
Inventory: 1204
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder, 4 Leads
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-TIF
Size / Dimension 0.433Dia 11.00mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.1A
Shielding Unshielded
Current Rating 1.1A
Inductance 470μH
Test Frequency 100kHz
DC Resistance (DCR) 460mOhm Max
Frequency - Self Resonant 1.6MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.3A
Inductance Tolerance 10%
RMS Current (Irms) 1.1A
Dimensions
Height Seated (Max) 0.669 17.00mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
