7447221103

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder, 4 Leads
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-TIF Radial Vertical Cylinder 4Leads 0.433Dia 11.00mm 10mH
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.462191
≥1 USD $1.462191
≥10 USD $1.379431
≥100 USD $1.301345
≥500 USD $1.227685
≥1000 USD $1.158189
Inventory: 1184
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height Seated (Max) 0.669 17.00mm

Technical

RMS Current (Irms) 230mA
Inductance Tolerance 5%
Current - Saturation 290mA
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 260kHz
DC Resistance (DCR) 9.7Ohm Max
Test Frequency 10kHz
Inductance 10mH
Current Rating 230mA
Shielding Unshielded
Current Rating (Amps) 230mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.433Dia 11.00mm
Series WE-TIF
Packaging Tray
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Package / Case Radial, Vertical Cylinder, 4 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
