Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD4 Nonstandard 0.866Lx0.591W 22.00mmx15.00mm 10muH
PDF
/
Buying Options
Total Price: USD $2.14
Unit Price: USD $2.1384
≥1 USD $2.1384
≥10 USD $2.04864
≥100 USD $1.84448
≥500 USD $1.70808
Inventory: 92
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 15.0114mm
Length 21.9964mm
Height Seated (Max) 0.307 7.80mm
Height 7.0104mm

Technical

Series Resistance 17.2mOhm
RMS Current (Irms) 6.5A
Inductance Tolerance 20%
Current - Saturation 10A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 22MHz
Max DC Current 6.5A
DC Resistance (DCR) 21mOhm Max
Test Frequency 100kHz
Inductance 10μH
Current Rating 6.5A
Depth 15mm
Shielding Unshielded
Current Rating (Amps) 6.5A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 17.2mOhm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.866Lx0.591W 22.00mmx15.00mm
Series WE-PD4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
