RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Cut Tape fixed air core inductor -40C~125C 3.2MHz 1.6Ohm Max 470muH
PDF
/
Buying Options
Total Price: USD $2.34
Unit Price: USD $2.3408
≥1 USD $2.3408
≥10 USD $1.84184
≥100 USD $1.6456
≥500 USD $1.41504
Inventory: 572
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.205 5.20mm

Technical

Inductance Tolerance 10%
Current - Saturation 500mA
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 3.2MHz
DC Resistance (DCR) 1.6Ohm Max
Inductance 470μH
Shielding Shielded
Current Rating (Amps) 300mA
Resistance 1.35Ohm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.500Lx0.394W 12.70mmx10.00mm
Series WE-PD3
Packaging Cut Tape
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
