74454220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD3 SMT SHIELDED POWER INDUCT
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.81104
≥100 USD $1.64472
≥500 USD $1.49688
Inventory: 463
Minimum: 1
-
+
Technical Details
Technical
Shielding Shielded
Inductance 220μH
DC Resistance (DCR) 800mOhm Max
Frequency - Self Resonant 4.5MHz
Inductance Frequency - Test 100kHz
Current - Saturation 700mA
Inductance Tolerance 10%
Current Rating (Amps) 450mA
Resistance 683mOhm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.500Lx0.394W 12.70mmx10.00mm
Series WE-PD3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height Seated (Max) 0.205 5.20mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
