RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Cut Tape Fixed Inductor -40C~125C 10MHz 800mOhm Max 68muH
PDF
/
Buying Options
Total Price: USD $2.16
Unit Price: USD $2.156
≥1 USD $2.156
Inventory: 980
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Cut Tape
Series WE-PD3
Size / Dimension 0.500Lx0.398W 12.70mmx10.10mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 620mOhm
Current Rating (Amps) 480mA
Shielding Shielded
Inductance 68μH
DC Resistance (DCR) 800mOhm Max
Max DC Current 480mA
Frequency - Self Resonant 10MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.1A
Inductance Tolerance 20%
RMS Current (Irms) 480mA

Dimensions

Height Seated (Max) 0.118 3.00mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
