74451215
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Cut Tape fixed air core inductor -40C~125C 6MHz 590mOhm Max 150muH
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.5256
≥1 USD $2.5256
Inventory: 571
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape
Series WE-PD3
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 410mOhm
Current Rating (Amps) 260mA
Shielding Shielded
Inductance 150μH
DC Resistance (DCR) 590mOhm Max
Frequency - Self Resonant 6MHz
Inductance Frequency - Test 100kHz
Current - Saturation 50mA
Inductance Tolerance 20%
Dimensions
Height Seated (Max) 0.115 2.92mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
