74438335220
RoHS
RoHS compliant
RoHS compliantPackage 1212 (3030 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-MAPI 1212 (3030Metric) 0.118Lx0.118W 3.00mmx3.00mm 22muH
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.382979
≥1 USD $1.382979
≥10 USD $1.30469
≥100 USD $1.230847
≥500 USD $1.161174
≥1000 USD $1.095449
Inventory: 7115
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 84 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1212 (3030 Metric)
Supplier Device Package 1212 (3030 Metric)
Material - Core Metal Composite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-MAPI
Size / Dimension 0.118Lx0.118W 3.00mmx3.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Molded
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 600mA
Shielding Shielded
Depth 3mm
Current Rating 600mA
Case Code (Metric) 3030
Case Code (Imperial) 1212
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 940mOhm Max
Max DC Current 600mA
Frequency - Self Resonant 12MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.6A
Inductance Tolerance 20%
RMS Current (Irms) 600mA
Series Resistance 940mOhm
Dimensions
Height 1.5mm
Height Seated (Max) 0.059 1.50mm
Length 3mm
Width 2.9972mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
