74437356010
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LHMI Nonstandard 0.362Lx0.244W 9.20mmx6.20mm 1muH
PDF
/
Buying Options
Total Price: USD $18.56
Unit Price: USD $18.56205
≥1 USD $18.56205
≥10 USD $15.2304
≥100 USD $14.75445
≥500 USD $14.2785
≥1000 USD $13.80255
Inventory: 1090
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6.1976mm
Length 9.1948mm
Height Seated (Max) 0.118 3.00mm
Technical
Current - Saturation 25.5A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 44MHz
DC Resistance (DCR) 8.35mOhm Max
Test Frequency 100kHz
Inductance 1μH
Current Rating 12.5A
Shielding Shielded
Current Rating (Amps) 12.5A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Molded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.362Lx0.244W 9.20mmx6.20mm
Series WE-LHMI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Supplier Device Package 8030
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
Alternative Model
