74437349100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LHMI Nonstandard 0.287Lx0.260W 7.30mmx6.60mm 10muH
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 13720
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 77 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Iron Powder
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-LHMI
Size / Dimension 0.287Lx0.260W 7.30mmx6.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Molded
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 3.2A
Shielding Shielded
Depth 6.6mm
Current Rating 3.2A
Frequency 12MHz
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 69mOhm Max
Max DC Current 3.2A
Frequency - Self Resonant 12MHz
Inductance Frequency - Test 100kHz
Current - Saturation 8A
Inductance Tolerance 20%
RMS Current (Irms) 3.2A
Series Resistance 69mOhm
Dimensions
Height 4.8mm
Height Seated (Max) 0.197 5.00mm
Length 7.3mm
Width 6.6mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
