7443641500
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCF Nonstandard 1.122Lx0.768W 28.50mmx19.50mm 15muH
PDF
/
Buying Options
Total Price: USD $10.51
Unit Price: USD $10.507
≥1 USD $10.507
≥10 USD $8.62125
≥100 USD $8.3524
≥500 USD $8.0826
≥1000 USD $7.8128
Inventory: 1134
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 2818
Material - Core Manganese Zinc Ferrite (MnZn)
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-HCF
Size / Dimension 1.122Lx0.768W 28.50mmx19.50mm
Tolerance ±15%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 30A
Shielding Shielded
Current Rating 30A
Inductance 15μH
Test Frequency 100kHz
DC Resistance (DCR) 2.4mOhm
Max DC Current 30A
Frequency - Self Resonant 11MHz
Inductance Frequency - Test 100kHz
Current - Saturation 26A
Inductance Tolerance 15%
RMS Current (Irms) 30A
Series Resistance 2.4mOhm
Ambient Temperature Range High 75°C
Dimensions
Height 18.5mm
Height Seated (Max) 0.728 18.50mm
Length 28.4988mm
Width 19.5mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
