7443630220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCF Nonstandard 0.846Lx0.827W 21.50mmx21.00mm 2.2muH
PDF
/
Buying Options
Total Price: USD $6.5
Unit Price: USD $6.5032
≥1 USD $6.5032
≥10 USD $6.38
≥100 USD $5.676
Inventory: 474
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 21mm
Length 21.5mm
Height Seated (Max) 0.551 14.00mm
Height 14mm
Technical
RMS Current (Irms) 28A
Inductance Tolerance 15%
Current - Saturation 52A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 32MHz
Max DC Current 28A
DC Resistance (DCR) 1.5mOhm
Test Frequency 100kHz
Inductance 2.2μH
Frequency 32MHz
Current Rating 28A
Depth 21mm
Shielding Shielded
Current Rating (Amps) 28A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 1.5Ohm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.846Lx0.827W 21.50mmx21.00mm
Series WE-HCF
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Manganese Zinc Ferrite (MnZn)
Number of Pins 3
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
