744323033
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCI Nonstandard 0.417Lx0.417W 10.60mmx10.60mm 330nH
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.6256
≥1 USD $3.6256
≥10 USD $3.5552
≥100 USD $3.2736
≥500 USD $3.1416
Inventory: 775
Minimum: 1
-
+
Technical Details
Technical
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Series Resistance 2.17Ohm
Inductance Tolerance 20%
Current - Saturation 36A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 119MHz
Max DC Current 18A
DC Resistance (DCR) 2.17mOhm
Test Frequency 100kHz
Inductance 330nH
Current Rating 18A
Depth 10.6mm
Shielding Shielded
Current Rating (Amps) 18A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.417Lx0.417W 10.60mmx10.60mm
Series WE-HCI
Physical
Supplier Device Package 1030
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 10.6mm
Length 10.6mm
Height Seated (Max) 0.122 3.10mm
Height 2.8mm
