744152
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Toroidal Active Iron Powder Fixed Inductor -40C~105C 5.4MHz 30mOhm Max 82muH
PDF
/
Buying Options
Total Price: USD $4.29
Unit Price: USD $4.2944
≥1 USD $4.2944
≥10 USD $3.86144
≥100 USD $3.43288
≥500 USD $3.00344
Inventory: 89
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter 28mm
Technical
Series Resistance 30mOhm
Current - Saturation 1.7A
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 5.4MHz
Max DC Current 5A
DC Resistance (DCR) 30mOhm Max
Inductance 82μH
Lead Pitch 10mm
Current Rating 7.7A
Depth 12mm
Shielding Unshielded
Current Rating (Amps) 7.7A
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Type Toroidal
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 1.102Diax0.472W 28.00mmx12.00mm
Series WE-SI
Operating Temperature -40°C~105°C
Physical
Material - Core Iron Powder
Package / Case Radial, Vertical Cylinder (Open)
Mounting Type Through Hole
Mount Wire
Supply Chain
Factory Lead Time 14 Weeks
