7440700150
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 15muH
PDF
/
Buying Options
Total Price: USD $13.53
Unit Price: USD $13.5318
≥1 USD $13.5318
≥10 USD $11.10265
≥100 USD $10.7559
≥500 USD $10.40915
≥1000 USD $10.0624
Inventory: 1172
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 8mm
Length 8mm
Height Seated (Max) 0.079 2.00mm
Height 1.8mm
Technical
RMS Current (Irms) 1.65A
Inductance Tolerance 30%
Current - Saturation 1.25A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 25MHz
Max DC Current 1.65A
DC Resistance (DCR) 140mOhm Max
Test Frequency 100kHz
Inductance 15μH
Current Rating 1.65A
Shielding Shielded
Current Rating (Amps) 1.65A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 117mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
