7440690016

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-TPC Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 1.6muH
PDF
/
Inventory: 6841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 8.001mm
Length 8.001mm
Height Seated (Max) 0.059 1.50mm
Height 1.35mm

Technical

Inductance Tolerance 20%
Current - Saturation 3.3A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 85MHz
Max DC Current 3.1A
DC Resistance (DCR) 35mOhm Max
Test Frequency 100kHz
Inductance 1.6μH
Current Rating 3.1A
Shielding Shielded
Current Rating (Amps) 3.1A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
