7440680010
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 1muH
PDF
/
Inventory: 3797
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-TPC
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 32mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.8A
Shielding Shielded
Current Rating 2.8A
Inductance 1μH
Test Frequency 100kHz
DC Resistance (DCR) 38mOhm Max
Max DC Current 2.8A
Frequency - Self Resonant 110MHz
Inductance Frequency - Test 100kHz
Current - Saturation 3.3A
Inductance Tolerance 30%
Dimensions
Height 1.1mm
Height Seated (Max) 0.047 1.20mm
Length 8.001mm
Width 8.001mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
