744066680
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 68UH 1.5A 216 MOHM SMD
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.4978
≥1 USD $0.4978
≥10 USD $0.4085
≥100 USD $0.39615
≥500 USD $0.38285
≥1000 USD $0.3705
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.161 4.10mm
Technical
Inductance Tolerance 30%
Current - Saturation 1.5A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 7MHz
DC Resistance (DCR) 216mOhm Max
Inductance 68μH
Shielding Shielded
Current Rating (Amps) 1.5A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
