74406043220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 22UH 1.23A 172 MOHM
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.841581
≥1 USD $0.841581
≥10 USD $0.793949
≥100 USD $0.74901
≥500 USD $0.706607
≥1000 USD $0.666611
Inventory: 3387
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.118 3.00mm
Technical
Inductance Tolerance 20%
Current - Saturation 770mA
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 25MHz
DC Resistance (DCR) 172mOhm Max
Inductance 22μH
Shielding Shielded
Current Rating (Amps) 1.23A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.189Lx0.189W 4.80mmx4.80mm
Series WE-LQFS
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 4828
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
