74406042047
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 4.7UH 2.39A 70 MOHM
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.800207
≥1 USD $0.800207
≥10 USD $0.754916
≥100 USD $0.712188
≥500 USD $0.671876
≥1000 USD $0.633836
Inventory: 1106
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 4818
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-LQFS
Size / Dimension 0.189Lx0.189W 4.80mmx4.80mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 2.39A
Shielding Shielded
Inductance 4.7μH
DC Resistance (DCR) 70mOhm Max
Frequency - Self Resonant 89MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.53A
Inductance Tolerance 30%
Dimensions
Height Seated (Max) 0.079 2.00mm
Compliance
RoHS Status ROHS3 Compliant
