744052150
RoHS
RoHS compliant
RoHS compliantPackage 2323 (5858 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 15UH 950MA 190 MOHM
PDF
/
Buying Options
Total Price: USD $1.25
Unit Price: USD $1.249071
≥1 USD $1.249071
≥10 USD $1.178372
≥100 USD $1.111669
≥500 USD $1.048748
≥1000 USD $0.989386
Inventory: 1142
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 2323 (5858 Metric)
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-TPC
Size / Dimension 0.228Lx0.228W 5.80mmx5.80mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 950mA
Shielding Shielded
Inductance 15μH
DC Resistance (DCR) 190mOhm Max
Frequency - Self Resonant 30MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.1A
Inductance Tolerance 30%
Dimensions
Height Seated (Max) 0.079 2.00mm
Compliance
RoHS Status ROHS3 Compliant
